Pentagonal Prism
Processing Capacity
Capable to realize the complete processes in optical design, instrument design, component high-precision molding,
planar processing, spherical processing, aspheric processing, coating, etc.
Applications
Photoelectric information; aerospace; new energy; nuclear power and nuclear energy equipment and other fields.
Performance
● Pentagonal prism is one of the redirectors for beam angle setting (90°). It serves two purposes: first, whatever
the angle of incidence on the first surface is, the outgoing light will turn the incident light to a certain angle (90°);
second, unlike a right-angle prism, the imaging has neither rotation nor specular reflection.
● Such prism is used for camera viewfinder. Pentagonal prism is most suitable for image observation systems or
measuring instruments.
Features
| Pentagonal Prism | |
| Model | Prism-P-X |
| Material | H-K9L(BK7), Quartz |
| Optical film | Specified by the customer |
| Surface precision |
λ/6 |
| Effective size | 95% |
| Optical axis deviation | ≤5 seconds |
| Surface quality | 20-10 |
| Dimensional tolerance | ±0.1mm |
